We are delighted that you have purchased one
of our products.
These are usage instructions to help you
familiarise yourself with your new purchase.
All the documents accompanying the product
must be read attentively before using the
Led Lenser Flashlight
product, preserved carefully and if the product
is transferred to a third party, the documents
must be handed over as well. This ensures that
maximum benefit is drawn from the product
and questions from users are anticipated before
they arise.
Led Lenser Headlamps
Above all, comply with the warnings and safety
instructions and dispose of the packaging
material properly.
Additional information for H14R.2 with “TEST-
IT” function
Your LED LENSER H14R.2 headlamp is
packaged with a “TEST-IT” function (item no.
7399-R). This allows users to test the brightness
while the product is still in the package. For
Led Lenser H14r.2 Instruction Manual
testing, simply push the yellow “TEST-IT” button
on the front of the package. When testing, please
do not look directly into the light.
The “TEST-IT” button is connected to the battery
housing of the H14R.2 via two wires and should
be removed prior to use.
To remove the “TEST-IT” button and wires, open
the battery box rear cover and remove 4xAAA
alkaline battery (see also “Changing of the
battery “further below). Separate the two “TEST-
IT” button wires from the battery housing by
pulling on each wire until it releases from the
battery housing. Insert the battery and noting
the correct polarity. Close the battery box rear
cover. Please dispose and recycle the packaging
and “TEST-IT” button with the wires according to
the local regulations.
Product
7299-R,
LED LENSER® H14R.2
7399-R,
LED LENSER® H14R.2 (Blister)
Version of the operating manual: 1.3
1. Battery set:
1 x Li-ion battery pack 3.7 V 4400mAh
Led Lenser H14r.2 Manual Pdf
4XAA alkaline battery (Blister)
2. Switching on and off
The H14R.2 has two switches. The front switch
is located on the right side of the headlamp
housing. This switch button is used to turn the
The Primera saw Nissan's multi-link front suspension applied to front-wheel drive for the first time. The 2.0-litre gasoline engine received a power upgrade in 1992 which gave the then eZX, (later renamed the eGT) 150 bhp from the standard 2.0-litre engine and a top speed of around 219 km/h (or 137 mph). Nissan primera p12 user manual free download. Nissan had deliberately targeted the car at the European market. It was introduced in 2002 and produced until 2008. The UK versions were withdrawn in 2006 due to sharp decline in sales.
H14R.2 ON/OFF. It is also used to activate the
various Light Programs and Lighting Functions
(see section 5.1) and the “Transport Lock”
function (see Point 7). The “Multi-function
Wheel” switch is located on the backside at the
upper part of the battery box. This allows you
to adjust the brightness and flash rate infinitely
and to change into different modes. In this
switch is also a battery indicator and the red
rear light located (see Section 5).
3. Focus
In the front, narrower region of the headlamp
housing is the reflector lens through which the
light of the white LED is focusable. The light
is focusable through our patented 'Advanced
Focus System', by pushing easily the lamp head
forward and backwards (Speed Focus).
You also can adjust the hinge of the headlamp.
Depending on whether you want to illuminate
an area in the distance or in front of you. For
this you can simply tilt the part of the lamp
head, which contains the reflector lens and
the white LED. The gradual detent allows also
intermediate positions.
4. Smart Light Technology (SLT)
Led Lenser H14r.2 Manual
The H14R.2 is equipped with our Smart Light
Technology (SLT). Thanks to the use of a
microcontroller, the light output of the white
front LED can be controlled and the user can
use various Energy Modes, Light Programs and
Light Functions. The red rear light also has two
light functions. Through the front switch and the
“Multi-function Wheel' switch on the back, the
handling is simple and user-friendly. To turn the
Led Lenser Usa
headlamp on and off and to select the various
Light Functions etc., the front switch has to be
used. (see point 5).
What basically applies is that the brightness
of the H14R.2 is monitored by the in-built
temperature control unit.
5. Light Programs and Light Functions
In the H14R.2 are equipped with one white LED
(LED = Light Emitting Diode) ,
The white LED is very strong, ideal for normal
use, for example if the Speed Focus or the
adjustment of the angle of light beam to the
horizontal should be used. This very bright
white light might be not good when your eyes
Led Lenser Warranty
have become accustomed through the so-called
dark adaptation to low ambient light.
5.1 Light Program White (Front light)
In H14.2, there are three different modes (Easy
Low, Easy Power, Signal). The default mode is
Easy Low.
When the product is off, press the “Multi-function
Wheel” switch the for 5 second, it will achieve
mode transition, blink for one time, that means
you has entered sub-mode one; blink for two
times, that means you has entered sub-mode
two; and 3 times blink for three times, that
means you has entered sub-mode three.
a) Light Mode one - Easy Low: when the product
is off, push the front switch hardly until you hear
click sound, the white LED will glows with lower
brightness (light function: Low Power); second
touch the white LED will glows full brightness
(light function: Power), third time touch the
button is off;
b) Light Mode two - Easy Power: when the
product is off, push the front switch hardly until
you hear click sound, the white LED will glows
with full brightness (light function: Power);
second touch the white LED will glows with
lower brightness (light function: Low Power),
third time touch the button is off;
c) Light Mode three - Signal: when the product
is off, push the front switch hardly until you hear
click sound, the white LED will glows with full
brightness (light function: Power); second touch
Led Lenser Repair
the white LED flashes frequently (12 Hz) (light
function: Signal), third time touch the button is
off;
02
English
Page 02-05
GB
