- Replaces Lopi and Avalon 200 watt ignitor part # 99300148 & 99300149. See below for install instructions. Fits: Avalon Pellet Stoves: Arbor Astoria Bay PI Astoria PS Avanti PI Avanti PS Newport Bay PI Newport PS Lopi Pellet Stoves: Heritage Bay PI Heritage Bay PS Leyden PS Pioneer Bay PI Pioneer PS Yankee Bay PI Yankee PS.
- Astoria PS Avanti PI Avanti PS Newport Bay PI Newport PS LOPI STOVES: Heritage Bay PI Heritage Bay PS Leyden PS Pioneer Bay PI Pioneer PS Yankee Bay PI Yankee PS. Part Numbers: 99300148 / 99300149 / PH-CI4. Specs: 250 Watts, 120V AC Igniter shaft measures 4' length from where the wires start to the tip.
Replacement Parts for Lopi Pellet Stoves - Includes Motors, Gaskets, Igniters, Switches, Sensors, Pipes and Cleaning Products. Select Your Lopi Stove Model Below. Lopi Fox Fire 400 PS Stove Parts. Lopi Fox Fire 400 PI Stove Parts. HERITAGE BAY PS.
3 8
Maintenance
Travis Industries
4061016
1 0 0 - 0 1 1 8 4
Replacement Parts
Door Replacement Parts
5
9
8
10
4
3
7
2
6
1
ID #
Description
Qty
Part #
ID #
Description
Qty
Part #
1
Door, Left
1
2
Door, Right
1
3
Door Gasket
1
4
Gasket Cement
1
5Glass Gasket
1
6
Glass
2
7
Glass Clip w Screws, Gasket
4
8
Door Hinge w Pins
4
9
Left Door Handle w Hardware
1
10
Right Door Handle w Hardware
1
Replacement Parts
Description
Part #
Description
Part #
ASHPAN ASSY - LEYDEN WD STOVE - COMPLETE - SERVICE PART
250-00160
GRIDDLE STOP - LEYDEN - 12 GA CR - 1.531 x 1.000
250-00240
AUGER DRIVE COLLAR, 1997 & UP - LARGE/SMALL PEL STOVE/INS
91002021
GROMMET, IGNITOR WIRE - LG P/S - BLACK RUBBER
100-02811
AUGER FLIGHT INSPECTION COVER - 16 GA EG - 6.812 x 4.674
210-02702
GSKT, CLEAN-OUT CVR, AST/LG PI - 3.250 x 2.750
100-03235
AUGER FLIGHT, 2000+ LRG PEL - - 2' PITCH
91002013
GSKT, COMB BLOWER (BODY), LRG - 10.505' x 7.782' x 1/8'
100-03206
AUGER MOTOR, ALL PS/PI EXCEPT - 93-96 PELLET INSERT (93-0194)
90-0191
GSKT, COMB BLOWER(MOTOR), LRG - 7.000' dia
100-03231
BLOWER, COMB, PELLET - LARGE - 2000 & UP
93005535
GSKT, EXHAUST PLATE - LG PEL# - 4.250' x 4.250'
100-03230
BLOWER, CONV, P2-8/11-15/G1-2 - 93-95BV, 91-96PS/PI, 00 LRG PS
98900755
HOSE NIPPLE, BARBED (DRAFT)
100-04307
BRUSH, BROOM STYLE # - REPLACES 93005530 & 93005531
100-04301
IGNITER, LG PS/PI - 2000 & UP - 250 WATT ELEMENT
250-00243
BURN POT, LG PS/PI-CORN & PEL - LRG- PS/PI ONLY - SERVICE PART
250-00128
OIL PAN, COMB BLOWER - LG PEL - 20 GA ALZ - 5.414 x 1.881
210-03216
CNTRL BRD, ALL PEL 1997 & UP# - LARGE OR SMALL PS & PI
250-00011
Lopi Pioneer Pellet Stove Manual
POWER CORD, PS/PI 1997 & UP # - 16 ga AWG w/RING & FML CNCTRS
93005015
CORD RESTRAINER
100-00112
REFRACTORY (BRICK) – 3 PIECE SET
250-00264
DOOR LEFT LYDN - NI COMPLETE - w/GLASS - SERVICE PART
250-00138
SHL, ASH DRAWER - LEYDEN - CAST IRON - SERVICE PART
250-00159
DOOR RIGHT LYDN - NI COMPLETE - w/GLASS - SERVICE PART
250-00137
SHL, ASH DRAWER FRONT - LEYDEN - CAST IRON - SERVICE PART
250-00157
DR STRIKER PLATEw/SCRWS - LYDN - SERVICE PART
250-00143
SHL, ASHLIP - LEYDEN NEW IRON - CAST IRON - SERVICE PART
250-00156
DRAFT (FLOW) SWITCH # - ALL PS/PI
90-0791
Product Types. User manual amazon fire 7.
SHL, GRIDDLE - LEYDEN - CAST IRON - SERVICE PART
250-00134
Fujitsu siemens lifebook e series user manual. Sound level according to Blue Angel standard.
DRAFT FLOW TUBING, ALL PS/PI - ALL PELLET FS & INSERTS
99300164
SHL, LEG - LEYDEN NEW IRON - CAST IRON - SERVICE PART
250-00136
FACE HINGE LEAF - LYDN - SERVICE PART
250-00227
SHL, OUTSIDE AIR COVR - LEYDEN - CAST IRON - SERVICE PART
250-00158
FIREBOX, SIDE LEFT, LEYDEN NI - CAST IRON - SERVICE PART
250-00151
SNAP-DISC - 120deg CERAMIC # - NORMALLY OPEN
100-00232
FIREBOX, SIDE RGHT, LEYDEN NI - CAST IRON - SERVICE PART
250-00152
SNAP-DISC - 120deg NO # - NORMALLY OPEN
100-00231
FUSE - 5AMP CONTROL BOARD# - NEW DIAGNOSTIC BOARD 2006'
250-00081
SNAP-DISC - 200deg NC # - NORMALLY CLOSED
100-00233
FUSE HOLDER (IN-LINE)
100-00210
THERMOSTAT, PELLET
100-00250
Pioneer User Manuals
FUSE, 5AMP, 5 - FOR INLINE # - FUSE ASSEMBLY - 93 & UP PEL
Lopi Pioneer Owner's Manual
93-0695
TOOL, GLASS LATCH/RESTRICT0R/ - SCRAPER
100-02302
FUSE, 6AMP, 5 - CONTROL BOARD - 1997 TO 2005' PS & PI
93005019
WIRE HRNS, PEL, JUMPER, LRG - - PELLET
100-00390
GLASS - LEYDEN WOOD - 11.062 x 8.437 SERVICE PART
250-00142
WIRE HRNS, PEL, PS/PI '2005+ - REPLACES OLD HARNESS 100-00393
250-00017
GLASS RPLCMNT SCRW PAK- LEYDEN - 8- STANDARD & 8- OVERSIZE
250-00179
WIRE HRNS, THERMOSTAT (20')
100-00400
